Potato receiving hopper BSB 4120 / BSB 4124

onionunloadingloading

The buckling construction on the discharge side of the moving floor ensures an optimally dosed transition between the receiving hopper and the product cleaner. The moving floor consists of two very heavy roller chains with transverse cleats mounted between them. Because the polyester-nylon cloth is mounted with excess length over the cleats, a favorable take-away effect is created. The moving floor is driven by an electric motor mounted directly on the gearbox. This results in better power transfer. The moving floor speed is continuously adjustable. If desired, the system can be expanded with automatic capacity control. This control unit is connected to the frequency converter and consists of a sensor for ultrasonic layer thickness measurement and a PLC-control. STANDARD EQUIPPED WITH .Heavy baseframe with standard option to mount the cleaner. .Double drive to the drive shaft of the unloading floor chains. The gear units are equipped with a direct drive, with separate engine cooling so that the engine is always optimally cooled. .The moving floor consists out of 2.000 mm or 2.400mm (depending on the model) wide tubular profiles, covered with a polyester nylon cloth. .The hollow sections are mounted on both sides on a rugged 4 inch heavy bottom chain. .Floor mat with stainless steel wear plates under the side seals, optimizing the life of the floor garment. .A in height-adjustable front panel for a flexible input of the crop. .Double sealing with rubber flaps, prrevending spillage during input. .Viewing grids in the side panels to be able to observe the product level.
