Tobacco harvester machine M20

self-propelled

Description Technical specifications Self-propelled agricultural machine for harvesting BURLEY tobacco plants to be stored on frames, directly on the farm plot and not in the tobacco dryer. Tobacco harvester. Burley Tobacco Burley tobacco harvester self-propelled, AWD •4-wheel drive, hydraulically controlled rear steering wheels, hydrostatic transmission •Variable transfer chain speeds controlled from the operator’s seat •SAUER control and dialog screen for automated part •Control screen for the PERKINS combustion engine •Control screen for the POCLAIN hydrostatic transmission •Waste disposal conveyor belt under turner/notcher •Automatic transfer chain tightener •Vision cameras, LED work lights •Adjustable forward speed limiter •Air-conditioned, spacious and comfortable cabin •Harvesting speed: up to 2 hectares per day (depending on plantation density) •Burley plants from Ø25mm to Ø60mm, planting between lines of 80 cm min. •Max. driving speed: 9.5 km/h in field mode and 25 km/h on the road (road approved) •Overall dimensions in mm: Width 3,588, length 10,661, Height 3,580 •Hydraulic oil tank: 600 Liters •GNR tank: 370 Liters •Weight when empty: 12.2 tons •Loading capacity of 7 frames including one in store •Road approved •Continuous improvement since 2013
