trailed fertilizer spreader / anhydrous / liquid
EQUI-FLOW™ 360 Yield Center

{{requestButtons}}

Characteristics

  • Mounting:

    trailed

  • Fertilizer type:

    anhydrous, liquid

Description

Uneven application from traditional anhydrous ammonia systems can rob your crop of yield from the start. 360 EQUI-FLOW with Liquimatic Technology takes a new approach to NH3 delivery for better row-to-row accuracy, improved sealing and a wider application window.
KEY FEATURES
- Precise row-to-row accuracy
- Wider window of application
- Keeps NH3 liquid all the way to the injectors
- Improved sealing at the injection point
PRECISION NH3 APPLICATION IS POSSIBLE
360 EQUI-FLOW keeps NH3 in a liquid state all the way down the knife. This ensures equal distribution from row to row. Testing conducted internally by the 360 Yield Center team revealed that cold flows systems have as much as 45 lbs of variance from knife to knife, with some rows as much as 22 lbs over target and some as much as 22 lbs under. 360 EQUI-FLOW showed only 8 lbs of variance, ranging from 4 lbs over target to 4 lbs under.
360 EQUI-FLOW uses a pressurized delivery system to keep anhydrous in the liquid form all the way to the knife because flow meters are accurate with liquid, but inaccurate with a mix of vapor and liquid. Rather than the 45 lbs of variation seen in tank-pressure systems, 360 EQUI-FLOW reduced variability to around 8 lbs.
