Gas generator set ESS-ACDC-125-WPG

weldingagricultural

Zero‑Carbon Farm – Save up to 60% on your electricity bill

• Solar + battery energy storage system = your own power plant on the farm
• Clean energy source
• Significantly lower electricity costs
• Expand grid capacity (no more overloaded transformers)

Product overview
The ESS-ACDC-125-WPG is an integrated hybrid PCS combining photovoltaic input, energy storage battery interface and optional diesel generator support. Designed for industrial applications, it provides multi-port intelligent energy dispatching with PV-first, peak shaving and valley filling strategies, hybrid multi-source supply and storage-backed backup. The unit supports wide voltage/frequency ranges and intelligent off-grid switching to ensure continuous supply for critical loads.

Key features

• Integrated hybrid PCS: PV, battery and diesel interfaces in a single cabinet for simplified system architecture.
• Flexible installation: compact, side-by-side installation for space-efficient deployment.
• Modular scalability: scalable parallel connection — up to 4 units in off-grid mode and up to 8 units in grid-connected mode.
• Advanced energy management: multi-port intelligent dispatch, PV-priority operation, peak shaving and valley filling.
• High performance: up to 97.5% max efficiency, low THDi/THDu and adjustable power factor for improved system performance.
• Diesel & STS support (optional): diesel generator input and STS (static transfer switch) options for backup and transfer functions.
• Wide operating range: IP55 protection, corrosion class C3 (optional C4/C5), operating temperature -30°C to +60°C and altitude up to 4000 m (derating >2000 m).

Technical specifications

• Model: ESS-ACDC-125-WPG
• Off-grid AC rated power: 125 kW
• Grid-tied rated power: 200 kW
• Battery voltage range: 680–900 V
• Max battery current: 200 A
• PV power (optional): 120 kW (60 kW optional)
• MPPT voltage range: 600–900 V
• Max PV voltage: 950 V
• Max PV input current: 200 A
• Max diesel generator input power (optional): 120 kW (40 kW / 80 kW optional)
• Max diesel input current: 228 A
• DC load (optional): 100 kW (60 kW optional)
• Overload capability: 1.1× 10 min, 1.2× 60 s @35°C (grid); 1.1× long-term, 1.2× 60 s @35°C (off-grid)
• Power factor: >0.99 (adjustable -1 ~ 1)
• THDi / THDu:
• STS (optional): 200 kW, max current 330 A, switch time
• Cooling: Air cooling
• Dimensions (W×D×H): 1250 × 1100 × 2100 mm
• Weight:
• Noise: ≤75 dB
• Protection level: IP55
• Corrosion class: C3 standard (optional C4/C5)
• Max efficiency: 97.5%
• Operating altitude: up to 4000 m (>2000 m derating)
• Operating temperature: -30°C ~ +60°C (>45°C derating)
• Humidity: 5–95% (non-condensing)
• Wiring: 3P+N+PE
• Communication: RS485, CAN, Ethernet — Modbus RTU, Modbus TCP, CAN2.0
