Mounted grain Cart TJP 30R

Overview
TJP 30R is a trailer-mounted fertilizer spreader available in two versions (TJP 30R /MS and TJP 30R /MR). This description summarizes machine capacities, standard equipment, optional accessories and the main technical data relevant for professional agricultural use.

Available Versions / Capacities

• TJP 30R /MS
• TJP 30R /MR

Standard equipment

• Adjustable track width from 1400 to 2130 mm (depending on homologation)
• Adjustable quick-fit spreader brackets for all AGRIMIX versions
• Support foot for working and transport positions
• Tires 11.5/80x15.3
• Hubs 60x60 S/F
• Removable light bar
• Provision for mounting telescopic support for controls
• Removable and height-adjustable towing hitch
• Approved wheel chocks for parking
• Chock holder

Optional accessories

• Additional PTO shaft — Cod. SPC-ALB 510700TS
• Complete third-link arm — Cod. TRA 00012
• Telescopic support for hydraulic or remote controls on cab side — Cod. SPC ZO015
• Step with platform — Cod. SPC ZD130
• Mudguards (pair) — Cod. SPC ZO021
• Removable light bar - STAINLESS STEEL — Cod. SPC ZO018/X
• Pair of tires 15.0/55/17 *10 PR — Cod. SPC ZO004/C
• Pair of tires 19.0/45/17 10 PR TVS — Cod. SPC ZO004/B

Technical data
Version | TJP 30R /MS | TJP 30R /MR
Length - mm | 2750 | 2750
Adjustable track - mm | 1400 - 2130 | 1400 - 2130
Trailer mass - Kg. | 352 | 352
Max load capacity - Kg. | 3000 | 3000

Notes
Empty weight (mass) is indicative; actual weight may vary depending on added accessories.

Characteristics / Technical specifications

• Available models: TJP 30R /MS, TJP 30R /MR
• Length: 2750 mm
• Adjustable track width: 1400–2130 mm
• Empty mass (indicative): 352 kg
• Maximum load capacity: 3000 kg
• Standard tires: 11.5/80x15.3
• Hubs: 60x60 S/F
• Light bar: removable (standard)
