Diesel fuel tank DTO series

horizontalsteelstorage

Above ground, horizontal, cylindrical, single wall tank, made in carbon steel S 235 JR, thickness 3 mm., for Diesel fuel storage. Fitted with support saddles, lugs for empty tank lifting and grounding rod. The DTO is equipped with a rectangular, metallic containment basin with capacity 110% and protection roof. The system is in compliancy with the Italian Ministerial Decree n° 22/12/2017. The DTO is available in various capacities from 1.000 to 25.000 L ( 9000 L max. Italy )and itt can be completed with a variety of dispensing units. STORAGE TANK: Horizontal cylindrical single wall tank, approved by the Italian Ministry of Interior, built in carbon steel sheet EN 10025, fitted with support saddles, anti-roll bases and grounding connections in AISI 304. Externally treated with: acid cleaning, one coat of primer and a finish coat of environmental friendly water based paint. The DIESEL TANK is equipped with: • Flanged manhole diam. Ø 420 mm., complete with: - 3” tank loading port fitted with brass quick coupling; - Homologated overfill shut-off prevention valve acting at 95% of tank capacity; - 1” ½ (2”) vent pipe fitted with flame-arrestor terminal; - Mechanical floating level sensor with analogue clock dial; - 1” spare port; • Lifting lugs for empty tank handling; • 1” suction line with ball valve, in line check valve VRL calibrated at 0,2 bar and SS galvanized pipe to dispenser unit; • 1”draining with dust cap;
