Diesel generator set 1500-22 DA TXstationary50 Hzair-cooled
Add to favorites
Compare this product
fo_shop_gate_exact_title
Characteristics
- Type
- diesel
- Portability
- stationary
- Frequency
- 50 Hz
- Cooling system
- air-cooled
- Emissions level
- Stage II
- Domain
- agricultural
- Power
Max.: 22 kVA
(29.9 hp)20 kVA
(27.2 hp)Min.: 0 kVA
(0 hp)- Voltage
230 V, 400 V
- Rotational speed
1,500 rpm
(9,425 rad.min-1)- Length
1,450 mm
(57 in)- Width
700 mm
(28 in)- Fuel tank capacity
135 l
(35.7 gal)- Height
1,500 mm
(59.06 in)
Description
AIR refrigerated 1.500 r.p.m. DIESEL
Max. power: 22 KVA // 17.600 W.
Cont. power: 20 KVA // 16.000 W.
Engine: DEUTZ F3L 2011
Nº Cil.: 3
24 HP
Tank fuel: 135 L
Consumption 75%: 3,4 L/H
Alternator: LINZ E1S13MF/4
Dimensions: 1.450 x 700 x 1.500 mm
Weight: 710 Kg.
