Hydrostatic tractor KR Series
4-cylinderwith cab3-point hitch

hydrostatic tractor
hydrostatic tractor
hydrostatic tractor
hydrostatic tractor
hydrostatic tractor
hydrostatic tractor
hydrostatic tractor
Add to favorites
Compare this product


Characteristics

Transmission
hydrostatic
Number of cylinders
4-cylinder
Other characteristic
with cab, 3-point hitch, front PTO
Engine power

78 ch
(78 hp)

Displacement

3,409 cm³
(115 US fl oz)

Wheelbase

2,200 mm
(86.6 in)

PTO speed

540 rpm, 750 rpm, 1,000 rpm
(3,392.9 rad.min-1, 4,712.4 rad.min-1, 6,283.2 rad.min-1)

Maximum speed

Min.: 1 km/h
(0.6 mph)

Max.: 39.9 km/h
(24.8 mph)

Fuel tank capacity

90 l
(23.8 gal)

Total length

4,117 mm
(162.1 in)

Total height

2,783 mm
(109.6 in)

Weight

2,450 kg
(5,401.3 lb)

Description

.Complied with two hydraulic pumps. One for the hydrostatic steering and one for the rest of the hydraulics which means there is sufficient pressure in the line for all functions ensuring safer, controlled steering and smooth, powerful bucket operation. .Conveniently placed controls are all within comfortable reach and color coding makes operation safe and easy. .Ride more comfortably over tough terrain with an adjustable ergonomic suspension seat. .Gas strut one piece pop up bonnet allows easy access to all regular maintenance points such as engine oil and filters for air, fuel and hydraulics, etc. .Exclusively designed Power Transmission offers better fuel efficiency and performance on Branson K Series tractors. .Climate controlled and well structured cab fully protects operators from dust and harsh weather conditions. .With a strong rear hitch lift capacity of 1,733kg Standard CAT II 3point Hitch allows Operators up to heavier implements. .3 speed independent PTO is standard equipment which allows operator to switch to approx 540 / 750 / 1,000rpm to operate implements more efficiently and also with greater fuel efficiency. .There are front and rear wind screen washers / wipers and the rear window pivots open horizontally both side windows can be cocked open slightly too.
