Diesel walk-behind tiller 600S 178 FE / 186 FE

Product overview
Walk-behind two-wheel tractor Yavuz 600S equipped with the Yavuz 178 FE / 186 FE single-cylinder diesel engine. Designed for general agricultural tasks requiring compact PTO-driven power.

Technical details
The unit features a 3 forward and 2 reverse gearbox with conical and bevel gear transmission. Safety is provided by an emergency engine stop system. Two upper and two lower power take-offs enable multiple implement configurations. Braking is via dry type conical brake lining (self-cooling); clutch is Italian type. Anchor size 65 cm and wheels 500-10. Electric start system.

Specifications

• Serial No: Yavuz 600S 178 FE / 186 FE
• Gear Box: 3 Forward and 2 Reverse Speed
• Transmission: Conical and Bevel Gear Transmission
• Safety System: Emergency Engine Stop System
• Power Take-off: Two each Upper Power Take-off and lower Power Take-off
• Brake: Dry Type Conical Brake Lining (Self-Cooling)
• Clutch: Italian Type
• Anchor Size: 65 cm
• Wheels: 500-10
• Engine: Yavuz 178 FE / 186 FE
• Engine Type: 4 Stroke with Direct Injection, Single-Cylinder
• Starting System: Electrical Start
• Cylinder Volume: 817 cm3
• Power and Rotation: 7 - 10 HP / 3600 rpm
• Engine oil capacity: 1.1 l
• Fuel tank capacity: 3.5 l
• Fuel Type: Diesel
• Air Filter: Oil-bath type
• Cooling System: Air pressured
• Weight: 140 kg
