Melon seed extraction machine NCK-07 KM

pumpkinwith cleaning system

General Description
The NCK-07 KM Watermelon Seed Harvester is an agricultural machine designed to separate and prepare watermelon, pumpkin and melon seeds for bagging. It separates seeds from pulp quickly and hygienically, reducing manual labor and accelerating harvest operations.

Working System
Products are fed manually into the machine and processed in a sieve drum system integrated into the machine frame. The drum design separates seeds from pulp and directs them to the cleaning stage. Cleaned seeds are discharged into 50 kg bags through a dedicated outlet that facilitates fast bagging. This model does not include automatic feeding; feeding is manual. The machine can operate stationary or while in motion.

Power and Performance
The machine includes a 225-liter water tank for seed washing. It is driven by the tractor PTO at 540 rpm. Required tractor power: 50 HP (40 kW). Rated working capacity: 20,000 kg/hour.

Advantages

• Multi-purpose: for watermelon, pumpkin and melon seeds
• Fast seed separation and cleaning
• Designed for filling 50 kg bags
• Steel construction
• Operates stationary or while moving
• Reduces manual handling

Specifications / Technical data

• Model: NCK-07 KM
• Application: Watermelon, pumpkin and melon seed harvesting
• Feeding: Manual (no automatic feeding)
• Separation: Sieve drum system
• Bagging: Discharge outlet for 50 kg bags
• Water tank capacity: 225 liters
• PTO speed: 540 rpm
• Required tractor power: 50 HP (40 kW)
• Working capacity: 20,000 kg/hour
• Dimensions (L × W × H): 3600 mm × 2450 mm × 1400 mm
• Weight: 950 kg
