Brushless electric motor FBM-B 3100

IP44maintenance-free

Product overview
The FBM-B 3100 is a brushless battery motor designed for portable pump applications. It operates without mains connection and is suitable for outdoor use. The motor is maintenance-free and accepts a replaceable Li‑ion battery providing up to 120 minutes runtime and a full recharge in approximately 30 minutes. The motor offers infinitely variable speed and can drive different pumps in succession.

Benefits

• No mains connection required
• Immediate and flexible use on site
• Battery runtime up to 120 minutes
• Battery recharge in ~30 minutes
• Replaceable Li‑ion battery
• Maintenance‑free operation
• Design awards: iF Award and Red Dot

Technical data

• Protection class: IP 44
• Ventilation: Internal
• Power: 100 W
• Voltage range: 110–120 V / 220–240 V
• Frequency: 50–60 Hz
• Speed control: Infinitely variable
• Weight: 1.2 kg

Downloads available
Datasheet, CE certificates, operating instructions and spare parts list are available in the product downloads section.

Characteristics / technical specifications

• Model: FBM-B 3100
• Type: Brushless battery motor
• Battery: Replaceable Li‑ion, rechargeable within ~30 min
• Battery runtime: Up to 120 minutes (depending on speed/load)
• Power: 100 W
• Voltage: 110–120 V and 220–240 V
• Frequency: 50–60 Hz
• Protection class: IP 44
• Ventilation: Internal
• Speed control: Infinitely variable
• Weight: 1.2 kg
• Operational note: Empties a 200 L drum in approx. 3 minutes at 15,000 rpm; approx. 10 × 200 L drums per full battery charge at 5,000 rpm
• Maintenance: Maintenance‑free
• Awards: iF Award and Red Dot Design Award
