Push lawn-mower ZILLA

gasoline

The lawn mower ZILLA is designed to mow grass on lawns, gardens, sports fields, and parks. The mower is mounted on micro tractors that have a three-point linkage system Category I and PTO. The chassis is made of metal sheet and a rotary cutting rotor of the rotating rotor blades and one counter blade. This allows to mow the grass, and crumble the crop residues, bushy-wooded lands, as well as shredding branches up to 25 mm with slope mowing area up to 12º. Features The two blades are attached to the ends of the rotor through angular gear. The lawn mower is based on four running wheels in their swivel casings. Technical specifications Mounting: Rear of the tractor - Three-point linkage Category 1 Drive - From the tractor PTO by articulated shaft and angular gear PTO rotation - 540 turns/min (left or right) Slope mowing area - 12º Working unit - The rotor with 2 replaceable blades Wheels - 4 In the swivel casing Cutting height regulation - 25 – 100 mm by spacers (washers) on the axis of 4 support wheels Ejection mowing grass choice - Manually by changing the appropriate position and mounting the body mower chassis and change of a cover type Ejection mowing grass shield - Right / Left / Rear Cooperating tractor - Min 10 kW / 13.6 Hp Cutting width - 1016 mm Mowing height regulation - Manual by supporting wheel and the tractor’s hydraulic lift Working speed - 7 km/h Working width - 1 330 mm Length - 1 200 mm Height - 850 mm Weight - 85 kg
