Towed hay conditioner S250

Overview
The S250 is a side-pull mower-conditioner engineered for compatibility with a wide range of tractors. Its compact 2.4 m cutting width suits smaller tractors and acreage while delivering efficient cutting and conditioning to accelerate dry down.

• PTO requirement: 41 PTO kW (55 PTO hp)
• Standard clevis hitch for simple hookup
• Optional equal-angle hitch for improved maneuverability in irregular fields
• Transport width equals cutting width for convenient field-to-field transport

Key features

• Quick Change Knife system reduces knife-change time without tools
• Modular-design cutterbar for easy serviceability and replaceable modules
• Gear-driven cutting platform for reliable disk drive
• Impeller (impeller conditioner) standard on this model
• Adjustable gauge shoes and low-profile cutterbar for consistent cut quality

Conditioner options
Multiple conditioner types allow matching the conditioner to crop and field conditions to minimize dry down time and preserve forage quality.

• Impeller – suitable for light-stemmed grasses and alfalfa (scuffing action)
• Urethane – soft roll, recommended for legumes and grasses
• V10 steel – increased crimping for faster dry down and improved wear life
• Tri-Lobe™ – patented chevron design to crimp and crush (premium option)

Cutterbar and maintenance
The John Deere cutterbar uses individual diagonal-cut removable modules to simplify service and improve reliability.

• Nodular iron modules resist impact damage
• Large idler gears reduce driveline speed and wear
• Shear hub protection (ShearHub) minimizes repair time and cost in the field
• Common oil bath for internal lubrication to reduce oil-level checkpoints
• Oil reservoir capacity: 5.7 L

Quick-change knives
The Quick Change Knife (QCK) system allows rapid knife swaps without tools or air compressors, reducing downtime.

• More than 50% faster knife change time compared with bolted systems
• Kits available to retrofit where applicable

Transport and windrow formation
Designed for narrow transport and customizable windrow formation to promote uniform drying.

• Side-pull models feature center tongue and top-entry drivelines to optimize transport width
• Quick transition between field and road transport configurations
• Adjustable swath boards and forming vanes allow on-the-go windrow width changes (large adjustments require no tools)
• Windrows with consistent volume, no clumping, square shoulders and even edges

Specifications

• PTO speed: 540 rpm
• PTO (power requirement at 540 rpm): 55–75 hp / 41–56 kW
• Power Take-Off options: 540 rpm (standard); 1000 rpm capability listed where applicable
• Standard hitch: Clevis
• Optional hitch: Equal angle
• Hydraulic pressure required: 13,790 kPa / 2,000 psi
• Cutterbar – cutting width: 2.4 m / 8.1 ft
• Cutterbar – cutting height: 2.8–9.8 cm / 1.1–3.8 in
• Number of disks / knives: 5 disks / 10 knives
• Disk speed: 2,650 rpm
• Knife tip speed: 307 km/h / 191 mph
• Impeller conditioner width: 140 cm / 55.2 in
• Impeller diameter: 59.4 cm / 23.4 in
• Impeller tines: V-tines (33 tines), two speeds, 3-V powerband drive
• Transport width: 2.4 m / 8.1 ft
• Transport length: 6.2 m / 20.6 ft
• Weight (impeller conditioner): 2,027 kg / 4,470 lb
• Standard tires: 11L-15 (optional 31x13.5L-15)
• Cutterbar protection: ShearHub
• Angle adjustment: Manual or hydraulic (2–8°)
• Date collected (specification data): August 24, 2020
