Rotary rake GA 7631 P

center deliverybi-rotorharvesting

Overview
Mounted twin-rotor rakes with central delivery, designed for medium tractors. They form central swaths for fast dry-down and easy pickup while offering good manoeuvrability for field work.

Product details
The GA 1001 P and GA 1031 P are mounted twin-rotor central-delivery rakes equipped with double-curved hyper-tangential mounted tine arms to ensure clean forage and uniform swath formation. Compact layout and a centre of gravity close to the tractor improve manoeuvrability. Low machine weight (approx. 1.2 t and 1.5 t respectively) and simple coupling allow use across a range of medium-power tractors.

Benefits

• Compact layout and improved manoeuvrability for easy handling with medium-sized tractors.
• Double-curved hyper-tangential tine arms provide clean forage and consistent central swaths to speed up dry-down.
• Quick coupling and straightforward adjustments reduce setup time in the field.

Characteristics / Technical specifications

• Type: Mounted twin-rotor rakes (central delivery)
• Models: GA 1001 P, GA 1031 P
• Raking delivery: central swath
• Raking concept: double-curved hyper-tangential mounted tine arms
• Working width: approx. 5.65 m to 7.50 m
• Machine weight: approx. 1.2 t (GA 1001 P), 1.5 t (GA 1031 P)
• Intended use: operation with medium-power tractors and easy coupling
