Filling Tunnel -
Type: - Oblong orflattened.
Admitted bag size: - 9 feet (2,74 m) - 60 and 75 meters
Bag mounting: - By means of rétractable support with winch and hanger.
Materials to be bagged - Ail kinds of dry grains.
Transport position - Identical to work. Does not require additional éléments Optional: set of wheel hubs, tongue and lights for end transport.
Working tongue - Foldable for end or truck transport.
Tract or requirement -
Minimum power: - 45 CV(din)
Power take off: - 540 RPM
Hydraulic System: - One double-acting hydraulic cylinder outlet.
Drive - Protected PTO shaft.
Safety System: - Torque limiter with shear boit.
Brake System - Disk brake on both wheels. Adjustable braking by manual operating pump. Indicating manometer.
Wheel axle - Adjustable by agricultural type hydraulic cylinder (3" or 3 W x 8").
Feed - High capacity auger (more than 250 ton/hour).
Auger diameter: - 450 mm
Bag rétention - With encirding elastic harness.
Tires - 7.00 - 15 - 8 ply - quantity 2
Total weight - 1250 Kgs
