Dump trailer OL TMK 340

3-axleagriculturalforestry

OL TMK 340 - Tridem axle dump truck Transport giant – powerful and reliable The OL TMK 340 tridem axle dump truck from Oehler sets new standards in terms of stability, performance, and versatility. This dump truck is specially designed for demanding transport tasks in agriculture, construction, and forestry. With a gross vehicle weight of 34,000 kg and a robust construction, it is ideal for heavy loads and large transport volumes. Permissible total weight: 34.0 t Box dimensions (internal): 9,155 (9,000) x 2,300 (2,240) x 1,600 mm Standard tires: 710/50 R 26.5 Unladen weight approx.: 10,500 kg Axles: Hydraulic ADR Alpha unit Platform height approx.: 1,645 mm with 710 wheels Base plate: 5 mm Maximum axle load capacity: 15 t Tilt cylinder stages: 6 Cylinder stroke height: 3,630 mm Tipping angle: 46° (rear) – 35° (side) Max. operating pressure: 200 bar Required oil volume: 56.2 l Brake: 2-circuit compressed air brake system Paint finish: 2K high-build epoxy wet paint system Standard equipment - Torsion-resistant chassis made of sturdy rectangular tubular frame - Steel side walls mounted separately with wear strip, grain slide, tension ropes - Conical bridge, central locking on 3 sides, bolted corner posts - Spring-loaded drawbar - Hydraulic support foot (scissor support foot)
