Tipping trailer OL TMK 160 SUMO

2-axleagricultural16 ton

OL TMK 160 SUMO - Tandem axle dump truck Permissible total weight: 16.0 t Box dimensions (internal): 5,000 x 2,240(2,300) x 1,500 mm Standard tires: 385/65 R22.5 MP27 retreaded 10L ET0 Unladen weight approx.: 4,500 kg Platform height approx.: 1,360 mm Floor plate: 5 mm continuous, unwelded Max. axle load capacity: 18,000 kg Tilt cylinder stages: 5 Cylinder stroke length: 2,500 mm Cylinder stages Ø mm: 75-90-105-120-140 Max. operating pressure: 180 bar Required oil quantity: 24.8 l Brake: 2-circuit compressed air brake system Electrical system: 12 volt lighting system, rear socket Other: Wheel chocks - Torsion-resistant chassis made of sturdy rectangular tubular frame, ACC primed, spring-loaded drawbar - Dual-circuit compressed air brake system - Side walls 4 mm, floor 5 mm - BPW axle: suitable for 25/40 km/h - Hydraulic support leg - 12-volt lighting system, rear socket - 2K paint finish (dump body) - Oversized tipping cylinder, 5-stage, 2,500 mm stroke, cardan-mounted with hard chrome-plated piston rod and automatic stroke limiting valve
