Front-mount mulcher TSG series

rear-mountknifeflail

Product overview
Flail shredder for orchard and vineyard row maintenance. Available in rear, front or reversible mounting. Working widths from 140 cm to 250 cm. Rotor configurable with hammers (standard) or knives.

Application
Designed for maintenance of orchard rows and vegetation management between vine and tree rows. Mounts on tractor three-point linkage; suitable for PTO at 540 rpm. Multiple models to match tractor power and working width requirements.

Technical features

• Standard casing thickness: 8 mm (optional 10 mm)
• Cutting elements: hammers (standard); knives optional
• Configurations: rear (standard), front, reversible
• Rotor diameters: 158 mm (most models), 168 mm (larger models)
• Roller diameter: 192 mm
• PTO speed: 540 rpm
• Max vine shoot diameter accepted: 40 mm
• Third point category: 3

Data sheet
Model | TSG 140 | TSG 160 | TSG 180 | TSG 200 | TSG 200S | TSG 220 | TSG 250
Working width | 140 | 160 | 180 | 200 | 200 | 220 | 250
Clearance area/size | 155 | 175 | 195 | 215 | 215 | 235 | 265
RPM | 540 | 540 | 540 | 540 | 540 | 540 | 540
Maces n. | 8 | 9 | 12 | 12 | 16 | 16 | 20
Weight (kg) | 550 | 600 | 650 | 700 | 700 | 750 | 850
Roller diameter (mm) | 192 | 192 | 192 | 192 | 192 | 192 | 192
Rotor diameter (mm) | 158 | 158 | 158 | 158 | 168 | 168 | 168
Recommended horsepower (CV) | 60 | 60 | 90 | 90 | 90 | 90 | 110
Number of belts | 3 | 3 | 4 | 4 | 4 | 5 | 5
Third point category | 3 | 3 | 3 | 3 | 3 | 3 | 3
Diameter of the vine shoot (mm) | 40 | 40 | 40 | 40 | 40 | 40 | 40
Type of coating | Spray water | Spray water | Spray water | Spray water | Spray water | Spray water | Spray water
Type of strap adjustment | Manual | Manual | Manual | Manual | Manual | Manual | Manual
Type of cardan joint | B6 | B6 | B6 | B6 | B6 | B6 | B6

Optional

• Hydraulic displacement
• Oversized rear roller
• Mini sled skates
• Casing increased thickness 10 mm
• Reinforced SKF supports

Compliance
Machine compliant with CE regulations.

Specifications

• Designed for orchard row maintenance
• Available configurations: rear, front, reversible
• Cutting elements: standard hammers or optional knives
• Standard casing thickness: 8 mm (optional 10 mm)
• Working widths available: 140–250 cm depending on model
• Recommended PTO speed: 540 rpm
• Rotor diameters: 158 mm and 168 mm
• Recommended tractor power range: 60–110 CV depending on model
• Number of belts: 3–5 depending on model
• Third point category: 3
• Vine shoot diameter capacity: up to 40 mm
