Lighting control system CONTROL

Dimensions:265 x 254 x 127 mm Power supply:85-265 V AC, 47-63 Hz Sensor input ports:3 x Senect sensors Output ports:1 x High-Power output, 2 x Actuator output ports, 3 x 230 VAC Signals of the actuator outputs:24 V DC PWM, 0-10 V, 4-20 mA Ingress protection:IP54 Data transmission:802.11 b/g/n 2.4 GHz WLAN, remote access via dynamic DNS, port forwarding and IPv4 Drum- and belt filter Controller •Suitable for every drum or belt filter •Reliable hydrostatic pressure sensor technology •Eco- and Dynamic-Mode: water- and energy-saving •WLAN: online alarm and monitoring Advantages through the intelligent filter control algorithms of SENECT Low maintenance and resource-saving through: •the intensive cleaning programme2 •the Eco Mode (saves up to 40% water)1 •the automatic water refill (with optionally available magnetic valve)1 Safety through: •Monitoring of water level and motor current (for 24 V DC motors)1,2 •Alarm messages in case of error on Smartphone, Tablet or PC •Alarm also possible with warning lamp or as signal to SPS •Remote access: insight into past actions, measured values and current status online User-friendly: •easy installation thanks to plug connectors •subsequent installation on almost every filter possible •operation directly on the device, but also conveniently via tablet or PC
