PTO-driven firewood processor JOBO WP50

Short description
A wood processor developed for lighter base machines. It performs two main functions: feeding and delimbing logs up to 2–20 cm diameter to required lengths, and an automatic sequence of feeding, cutting and splitting firewood. From tree to firewood in one single operation. Built in modular modules to meet the requirements of the base machine and specific user needs. Its low hydraulic flow demand makes it suitable for older tractors driven directly from their own hydraulic flow.

Appendices

• WP50 TRACTOR v3

Technical data
Tree diameter: 2–20 cm, delimbing length: 15 cm
Stroke cylinder: 50 cm, 1.3 tonne at 160 bar
Oil demand: 15–35 l/min, operating pressure: 150–190 bar

Key features

• Designed for lighter base machines and tractor mounting
• Functions: feeding and delimbing to required lengths; automatic feed, cutting and splitting of firewood in a single operation
• Modular construction to adapt to base machine and user requirements
• Low hydraulic flow requirement suitable for older tractors driven directly from tractor hydraulics
