Utility tractor TAFE 5515

synchromesh mechanical shiftmechanical shuttle3-cylinder

Overview
TAFE 15 Series agricultural tractors. The TAFE 5515 is a 4WD model engineered for field versatility, operator ergonomics and efficient implement operation.

Key specifications (summary)

• Engine power: 55 hp
• Transmission: 12 F + 12 R (Synchromesh)
• Drive: 4WD
• PTO: 2-speed independent PTO (IPTO)
• Engine type: 3-cylinder, 2600 cc
• Fuel capacity: 75 L
• Lift capacity: 2400 kg
• Steering: Power steering
• Brakes: Oil-immersed brakes

Features

• Diesel engine compliant with Euro Stage V for regulated emissions control.
• Three-cylinder engine tuned for continuous agricultural operation and fuel efficiency.
• 12F/12R synchromesh mechanical shuttle transmission for smooth gear changes and field maneuvering.
• Dual-speed independent PTO (IPTO) to adapt to a wide range of implements.
• Split-torque, low-effort clutch to reduce operator fatigue and extend clutch life.
• TAFE SY hydraulics with fully submerged scotch yoke pump for consistent flow, reduced wheel slip and longer component life.
• M-Lift automatic implement height adjustment for stable positioning during field and headland tasks.
• Operator-focused layout and controls to support productivity during long work cycles.

Technical specifications

• Series: TAFE 15 Series (Magna Series)
• Model: TAFE 5515
• Engine power: 55 hp
• Engine configuration: 3-cylinder, 2600 cc
• Emission standard: Euro Stage V compliant
• Transmission: 12 F + 12 R, synchromesh mechanical shuttle
• Drive: 4WD
• PTO: 2-speed IPTO (independent power take-off)
• Hydraulics: TAFE SY hydraulics with fully submerged scotch yoke pump
• Lift capacity: 2400 kg
• Fuel capacity: 75 L
• Clutch: Split-torque low-effort clutch
• Brakes: Oil-immersed brakes
• Steering: Power steering
