Vine stalk picking machine RMS series

towed

Product overview
TERRAL Vine picker collects vine shoots and pruning debris from vineyards. It extracts material without shredding, leaving the plot free of remnants.

Function
The machine gathers vine shoots and pruning waste into a collection basket without shredding.

Use
Operate after vine pruning (January–April). Best on relatively bare soil; vegetation must not exceed 20 cm in height. Suitable for stony ground or early cover crops; usable on all soil types.

Operation
The frame's curved teeth and stabiliser skids collect even the smallest wood pieces and deposit them into the basket. When the basket is full, operating the jack closes it and ejects the bundle of shoots.

Hitch
Fits to the rear of the tractor (rear hitch only) to allow combination with a front-mounted tool such as a TERRAL windrower.

Feed rate
Working speed: 2–5 km/h depending on the quantity of shoots.

Vine picker versions

• 9 tooth
• 11 tooth

Standard features

• Double-girder chassis made of moulded steel
• CAT1 3-point hitch
• Manually adjustable working width
• Height-adjustable teeth
• Height-adjustable depth skids
• Basket locks with single-acting cylinder
• Storage struts

Technical specifications

• Model name: Vine picker
• Manufacturer / Brand: TERRAL
• Attachment: Rear of tractor only; CAT1 3-point hitch
• Recommended operating period: After pruning (January to April)
• Recommended ground/vegetation: Best on relatively bare soil; suitable for stony ground or early cover crops; usable on all soil types
• Maximum recommended shoot height before collection: 20 cm
• Feed rate (working speed): 2–5 km/h depending on vine quantity
• Versions available: 9 tooth, 11 tooth
• Chassis: Double-girder chassis made of moulded steel
• Adjustments: Manually adjustable working width; height-adjustable teeth; height-adjustable depth skids
• Collection system: Curved teeth and stabiliser pads collect small pieces; basket receives material; basket closed and emptied via jack (single-acting cylinder for basket locks)
• Storage: Storage struts provided
