Zinc-coated steel hose clamp W1

worm

Product
W1 hose clamps for industrial hose and coupling connections, zinc-plated steel construction. Available for diameters from 17 mm to 260 mm.

Product table
Item | Code | Ø (mm)
C774000 | 74000 | 17-19
C774001 | 74001 | 20-22
C774002 | 74002 | 23-25
C774003 | 74003 | 26-28
C774004 | 74004 | 29-31
C774005 | 74005 | 32-35
C774006 | 74006 | 36-39
C774007 | 74007 | 40-43
C774008 | 74008 | 44-47
C774009 | 74009 | 48-51
C774010 | 74010 | 52-55
C774011 | 74011 | 56-59
C774012 | 74012 | 60-63
C774013 | 74013 | 64-67
C774014 | 74014 | 68-73
C774015 | 74015 | 74-79
C774016 | 74016 | 80-85
C774017 | 74017 | 86-91
C774018 | 74018 | 92-97
C774498 | 74019 | 98-103
C774020 | 74020 | 104-112
C774021 | 74021 | 113-121
C774022 | 74022 | 122-130
C774023 | 74023 | 131-139
C774024 | 74024 | 140-148
C774025 | 74025 | 149-161
C774026 | 74026 | 162-174
C774504 | 74027 | 175-187
C774512 | 74028 | 188-200
C774503 | 74029 | 201-213
C774030 | 74030 | 214-226
C774513 | 74031 | 227-239
C774032 | 74032 | 240-252
C774509 | 74033 | 240-260

Other related products

• Union nut – SS304 – for SMS food couplings
• Camlock gaskets
• Type A

Characteristics / technical specifications

• Material: zinc plated steel
• Model / series: Clamps W1
• Product type: Hose/clamp coupling clamp (W1)
• Available items and sizes (Item – Code – Ø mm):
  • C774000 – 74000 – 17-19 mm
  • C774001 – 74001 – 20-22 mm
  • C774002 – 74002 – 23-25 mm
  • C774003 – 74003 – 26-28 mm
  • C774004 – 74004 – 29-31 mm
  • C774005 – 74005 – 32-35 mm
  • C774006 – 74006 – 36-39 mm
  • C774007 – 74007 – 40-43 mm
  • C774008 – 74008 – 44-47 mm
  • C774009 – 74009 – 48-51 mm
  • C774010 – 74010 – 52-55 mm
  • C774011 – 74011 – 56-59 mm
  • C774012 – 74012 – 60-63 mm
  • C774013 – 74013 – 64-67 mm
  • C774014 – 74014 – 68-73 mm
  • C774015 – 74015 – 74-79 mm
  • C774016 – 74016 – 80-85 mm
  • C774017 – 74017 – 86-91 mm
  • C774018 – 74018 – 92-97 mm
  • C774498 – 74019 – 98-103 mm
  • C774020 – 74020 – 104-112 mm
  • C774021 – 74021 – 113-121 mm
  • C774022 – 74022 – 122-130 mm
  • C774023 – 74023 – 131-139 mm
  • C774024 – 74024 – 140-148 mm
  • C774025 – 74025 – 149-161 mm
  • C774026 – 74026 – 162-174 mm
  • C774504 – 74027 – 175-187 mm
  • C774512 – 74028 – 188-200 mm
  • C774503 – 74029 – 201-213 mm
  • C774030 – 74030 – 214-226 mm
  • C774513 – 74031 – 227-239 mm
  • C774032 – 74032 – 240-252 mm
  • C774509 – 74033 – 240-260 mm
• Packaging, weight, certifications or application notes: not specified on the page
