Feed conveyor CST

screw

SWEEP AUGER CST The CST range of sweep augers is manufactured to suit a wide range of silo diameters & is designed to be permanently installed in the silo & can be used with free flowing granular materials. Three reclaim capacities are available; the direct coupled gear motor drive can be mounted either in the silo or, at additional cost, in the gallery under the silo. SWEEP AUGER MODEL CST This compact, permanent sweep auger with an apex cover, direct geared motor drive, slip ring & progression with walking plates is available with capacities from 30 to 50 t/h & is suitable for silos from model FP06 to FP18. ATEX standard is available at additional cost. The apex cover & mounting frame are galvanized finish. SWEEP AUGER MODEL CSTF Three reclaim capacities are available; the direct coupled gear motor drive can be mounted either in the silo or, at additional cost, in the gallery under the silo. The CSTF permanent sweep auger has a painted apex cover with bolted flange connections, direct geared motor drive, slip ring & progression with walking plates is available with capacities from 30 to 50 t/h & is suitable for silos from the models FP18 to FP26. ATEX standard is available at additional cost. The mounting frame is galvanized. SWEEP AUGER MODEL CSTFR / CSTFRH The drive assembly is mounted on a heavy painted central support frame and ATEX specifications are available. A heavier construction machine, the CSTFR sweep auger also has a capacity of 30 to 50 t/h & is suitable for silo models FP20 to FP26 with ATEX standard drives available if required.
