Mechanical transmission tractor 15034
with cab3-point hitch

mechanical transmission tractor
mechanical transmission tractor
Add to favorites
Compare this product


Characteristics

Transmission
mechanical transmission
Other characteristic
with cab, 3-point hitch
Engine power

147 kW
(200 hp)

Description

ENGINE Engine (brand and model) DEUTZ BF6M1013EC Engine type turbocharged with intercooler Power kW/HP at rpm 147 /200 - 2300 Max. torque, Nm at rpm 727 - 1400 Capacity [cm3] / number of cylinders 7145 /6 Air filter 2-stage, dry type with contamination sender Fuel tank capacity, l 330 TRANSMISSION Clutch Automatic - 6 F / 1 R with front drive engagement Gearbox GHM MTC 60/420 Distributor box - 50/50% for rear and front axle Rear axle With planetary hub reduction units and hydraulically actuated brakes Front axle with planetary hub reduction units and brakes Maximum speed, km/h 45 HYDRAULIC LIFT SYSTEM Pump capacity, l/min 90 Nominal pressure, MPa 18 External hydraulics spool valves Single spool valve (2 quick -couplings) STEERING SYSTEM Steering system hydrostatic BRAKING SYSTEM Service brake oil immersed disc brakes hydraulically actuated, acting on rear and front wheels Parking brake mechanical, hand actuated
