Analog veterinary X-ray system MX-2

for horsescattlemobile

Large Animal Mobile Vet Digital System Now Mobile X-rays are easier than before! • Motorized Unit. 4 km/h speed. Pressure Sensitive Moving System • Two independat motors for each wheel. Forward and backward movement • Excellent mobility even over small obsticles • Independant Charge Indicators for Drive and Generator Batteries • Anti Collision System. • Handle Release Brake System • Manual collimator • Ergonomic touch screen control panel • Emergency stop push button • Counterbalanced tube arm • Lock release control on front of tube head • Tube Stand Column Rotation +/- 270o • Tube Rotation “X” axis +/- 180o • Tube Rotation “Z” axis 90o • Vertical Tube Travel 59” • Horizontal Tube Travel 22” • Maximum Focal Distance 79.72” to the floor • Minimum Focal Distance 22.64” to the floor SPECIFICATIONS X-RAY GENERATOR kW Rating 50 kW kVp Range 40 to 150 kVp mA Range 10 - 500 mA Selectable Number of Stations 18 Exposure Time Range 0.001 - 10 sec. mAs Range 0.1 - 500 mAs Generator Integration Yes, 3 PT technique Battery / Capacitor Battery / Capacitor Anatomical Programs 500+ Anatomical settings
