Cubicle bedder 2918A

Standard equipment:

• Distribution of loose/dry feed such as maize and short grass
• Conveyor: transmission belt
• Two hatches for left and right distribution
• Height: 1200 / 1100 mm; Depth: 1260 mm
• Hydraulic drive
• Steel wear blade
• Euro mount (standard)

Optional equipment:

• Hydraulic rotor
• Gripper for bedding & feeding shovel
• Two anti-blocking rollers
• Hydraulic hatch opening
• Alternative mount types

Product number:
2918A;2919A

Technical data:
Ref. No | Working width [m] | Weight [kg] | Capacity [m3]
2918A | 1.22 | 300 | 1.1
2919A | 1.52 | 350 | 1.3

Technical specifications:

• Model name: MINI
• Application: distribution of loose/dry feed (e.g. maize, short grass)
• Conveyor: transmission belt included
• Distribution: two hatches (left and right)
• Height: 1200 / 1100 mm
• Depth: 1260 mm
• Working widths: 1.22 m (ref. 2918A) and 1.52 m (ref. 2919A)
• Weight: 300 kg (ref. 2918A) and 350 kg (ref. 2919A)
• Capacity: 1.1 m3 (ref. 2918A) and 1.3 m3 (ref. 2919A)
• Drive: hydraulic drive (standard)
• Wear parts: steel wear blade
• Mount: Euro mount (standard); other mounts available as optional
• Optional features: hydraulic rotor; gripper for bedding & feeding shovel; two anti-blocking rollers; hydraulic hatch opening
