WiFi antenna Combi

GNSSMIMOdual-band

Compact and robust combi antenna for outdoor use on vehicles with five antenna elements and excellent reception characteristics. Specifications Antenna elements: - •Two isolated high-power antenna elements for 617-960/1710-6000 MHz for MiMo/Diversity applications (4G and 5G) •Two dual-band antenna elements for 2.4 Ghz & 4.9 – 7.2 GHz WiFi •High-performance GPS/GNSS antenna with integrated 26dB LNA and high-quality signal •filtering for best positioning accuracies, minimisation of possible interference in 4G band B13/14 Housing: - •Colour: white •Dimensions: Ø180 mm x 75 mm •Metal ground plane not required, all antenna elements retain their high performance even when mounted on non-metallic surfaces •Sealing after assembly IP69K Connections: - •2 x 30cm 4G / 5G with SMA plug •2 x 30cm WiFi with SMA socket •1 x 30cm GNSS with FME socket •With cable set or adapters directly to the five SMA connectors of the Neural-Box
