Gasoline generator set 180 KT CCmobile50 Hzair-cooled
Add to favorites
Compare this product
fo_shop_gate_exact_title
Characteristics
- Type
- gasoline
- Portability
- mobile
- Frequency
- 50 Hz
- Cooling system
- air-cooled
- Application
- welding
- Domain
- agricultural
- Power
Max.: 5 kVA
(6.8 hp)Min.: 0 kVA
(0 hp)4 kVA
(5.4 hp)- Voltage
230 V
- Rotational speed
3,000 rpm
(18,850 rad.min-1)- Length
950 mm
(37 in)- Width
730 mm
(29 in)- Noise level
97 dB
- Fuel tank capacity
6 l
(1.6 gal)- Height
700 mm
(27.56 in)
Description
Engine: KIOTSU KT 420
Alternator: LINZ E2W10 180 MDC
Max. power: 5 KVA // 4000 W.
Nom. power: 4 KVA // 3200 W.
Consumption (75%): 2,1 L./H.
Tank fuel: 6 l.
Electrode max. 3,25 mm. Rutile
Intensity 150 A. (30%) // 120 A. (60%)
Tension 230 V. // 50 Hz.
Noise level 97 dB
Weight: 94 kg.
Hand start
Dimesions 950 x 730 x 700 mm.
Welding kit included
