Ball valve 0300408.080320

PTFEpolypropylenethreaded

Ball valve in glass-fiber reinforced white polypropylene with a GAS (cylindrical) female thread on one end and a metric-profile male thread on the other. Sealing is provided by a food-grade NBR O-ring. The valve is full-bore: the sphere bore corresponds to the tube internal diameter.

Available variants

• 0300408.080320 — G: 1/2"; DN: 15; D: 20; M: M29X1,7; L(1): 16; L: 10; H: 78; H1: 93; E: 49
• 0300408.080525 — G: 3/4"; DN: 20; D: 25; M: M36X3; L(1): 19; L: 14; H: 89; H1: 110; E: 54
• 0300408.080730 — G: 1"; DN: 25; D: 30; M: M42X3; L(1): 22; L: 14; H: 96; H1: 125; E: 59

Technical specifications

• Connection standards: external metric thread and internal cylindrical GAS ISO 228/1
• Full bore: sphere hole equals tube internal diameter
• Materials: glass-fiber reinforced polypropylene (body); food-grade NBR (O-ring); PTFE (seat)
• Colors: Red (RAL 3031) and White (RAL 9003)

Documentation

• 3D models and product sheet available as a downloadable ZIP file from the product page
