Maize harvesting header Tez CH850

foragefor forage harvesterssilage

Description
The TEZ CH850 is a row-independent maize silage harvester that cuts two rows simultaneously regardless of sowing alignment or spacing. It is intended for medium to large farms, fodder contractors and silage operations requiring flexible, high-throughput harvesting.

Overview
Compatible with tractors providing a minimum of 65 HP via PTO (540 RPM), the CH850 uses a fully hydraulic drive, a multi-speed gearbox and a stainless-steel cutting disc with 12 high-speed blades to deliver uniform chopping and high throughput up to 8 MT/hour (dependent on crop and field conditions).

Key Features

• Row-independent operation: harvests two maize rows at once without fixed row spacing.
• Capacity: up to 8 MT/hour (crop- and field-dependent).
• PTO-driven: designed for 540 RPM PTO; minimum tractor power 65 HP.
• Cutting system: stainless-steel disc with 12 high-speed blades; chopping and shredding knives for controlled particle size.
• Compact footprint and defined kerb weight for stable field operation (dry: 1,160 kg).

Smart Harvesting Mechanism

• Dual-stage foldable discharge chute with optional extension for direct trailer loading.
• Feed system with rollers, three feeding guide plates and a feeding drum to ensure steady material flow.
• Built-in sharpener and self-sharpening disc to reduce maintenance downtime.
• Multi-speed gearbox for operation across varied crop densities and forward speeds.

Trolley System & Field Adaptability

• Optional tractor-mounted trolley support with 3000 kg capacity (dimensions: 5 x 5 x 5 ft).
• Trolley unloading via two hydraulic cylinders for controlled discharge.
• Reverse-mode operation supported (reverse gear + back steering) for precise alignment during loading and manoeuvres.

Designed for Indian Conditions
The TEZ CH850 integrates flexible power transmission, gearbox-driven motion and tractor-compatible hydraulics to handle uneven terrain, variable plant densities and irregular sowing patterns common in Indian fields. Suitable for cluster-level silage projects, contractor fleets and larger dairy operations.

Product Specifications

• Model: TEZ CH850
• Harvesting mode: Row-independent, 2 rows simultaneously
• Output capacity: Up to 8 MT/hour (depending on crop/field conditions)
• Working width: 1280 mm
• Working rows: 2 rows
• Recommended power source: Tractor PTO (minimum 65 HP)
• PTO speed: 540 RPM
• Kerb weight (dry): 1,160 kg
• Dimensions (L x W x H): 1220 mm x 1300 mm x 3200 mm
• Cutting system: Stainless-steel disc system with 12 high-speed blades
• Processing: Chopping and shredding knives for uniform particle size
• Drive & control: Fully hydraulic mechanism; multi-speed gearbox
• Feed system: Feed rollers with overload protection; feeding guide plates (3 nos.); feeding drum
• Maintenance: Built-in sharpener and self-sharpening disc
• Discharge: Dual-stage foldable chute with optional chute extension
• Trolley (optional): Tractor-mounted trolley support, 3000 kg capacity, hydraulic lifting with two cylinders
• Operation modes: Reverse-mode operation supported (reverse gear + back steering)
