Trailed sprayer Leeb GS series
folding armspneumatic

trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
trailed sprayer
Add to favorites
Compare this product


Characteristics

Mobility
trailed
Other characteristics
folding arms, pneumatic
Capacity

Min.: 6,000 l
(1,585 gal)

Max.: 8,400 l
(2,219 gal)

Working width

Min.: 18 m
(59'00" )

Max.: 45 m
(147'07" )

Pump capacity

400 l/min, 1,000 l/min
(105.7 us gal/min, 264.2 us gal/min)

Pump pressure

8 bar
(116 psi)

Description

The basis ■ Solidly désignée! frame made of quality Steel ■ Optional: air-suspended axles with level compensation ■ Solid drawbar connection for large clearance with standard lower linkage in a trailer hitch bail Steering axle - less tramline damage (optional) ■ Steering axle for stable positioning of the boom with high stability and exact tracking to avoid tramline damage ■ Optimal, even in uneven terrain ■ Large steering angle due to a taper-cut frame design Large tyres - less ground pressure ■ Wheels with diameter of up to 2.05 m ■ Maximum ground contact area with perfectly adapted air pressure ■ Adapted Tyre Pressure Control - automatic tyre pressure régulation that is completely integrated in the software
