Loader wagon Palès 200

mounted2-axleagricultural

Cutting system 2 drums rotary mower (2×4 blades, oil bath case, free wheel incorporated Cutting width 2100 mm Height setting of the rotary cut thanks to 2 hydraulic cylinders Cutting system suspension by 2 springs Cutting indicator position Conveyor width 950 mm composed of 6 combs equipped with 8 teeth and 8 blades Hydraulic driving of the conveyor by an hydraulic moto reductor with oil bath Cutting system protection cover Unloading Floor conveyor Marine chain Ø12 (haute résistance) bars made of dismantables tubes with manufactured ends ® Driving of the floor conveyor by moto reductor oil bath, flow adjustment 2 shredding rotors hydraulic driving Palès 200 – 300 6 shredding rotors hydraulic driving Palès 300 XL Rear bilateral unloading floor in PVC, width 800 mm and unloading height 700 mm Rear unloading with a complete hydraulic opening Control Electric control of all the functions with a mobile control box in the tractor’s cab Hydraulic group of the conveyor and the rotors, hydraulic oil tank capacity 200l Conception – Safety Bolted housing Lateral door Road traffic Low linkage beam with hydraulic dish Linkage under the transmission Parking brake and hydraulic brake on the 4 wheels Light in accordance with the road code Revolving light Hydraulic kickstand with manual pump Pendulum 4 wheels 400 x 15.5 CE norms and DREAL homologation
