Truck-mounted mixer DBM series

2-auger

Product overview
DBM is a truck-mounted concrete mixer combining a mixing drum and integrated auxiliary equipment to produce ready-mix concrete directly on site. It is designed for autonomous operation to mix, load and discharge concrete where required without additional plant.

Main features

• On-site mixing with a truck-mounted mixing drum for immediate concrete production.
• External ground/drum controls: drum controls replicated outside the machine to allow unloading from ground level without moving the vehicle.
• Dedicated DBM cab configuration and drum housing designed for operator visibility and control.
• Self-loading bucket and discharge arrangement for efficient loading and unloading operations.
• Axles and brakes sized and reinforced for mixer application.
• Integrated water pump and water tank to manage mixing water supply on board.

Variants (comparison)
Model | DBM2500 | DBM3500
Operating weight (kg) | 7050 | 7400
Concrete yield capacity (l) | 2500 | 3500
Drum volume (l) | 3500 | 5000
Bucket capacity (l) | 700 | 700
Water pump capacity (l/min) | 250 | 250
Water tank (l) | 930 | 930
Lift height at max. load capacity (mm) | 1760 | 2060
Drum rotation speed (rpm) | 0 ÷ 26 | 0 ÷ 18

Notes

• Values shown are published variant specifications (operating weight, capacities, speeds and heights) for the DBM family.
• Configuration and fitted equipment may vary by variant; verify the selected variant for exact equipment and capacities.

Technical specifications

• Model name: DBM
• Equipment type: truck-mounted concrete mixer (special machine)
• Concrete yield capacity: 2,500 l (DBM2500) / 3,500 l (DBM3500)
• Drum volume: 3,500 l (DBM2500) / 5,000 l (DBM3500)
• Bucket capacity: 700 l (both variants)
• Operating weight: 7,050 kg (DBM2500) / 7,400 kg (DBM3500)
• Maximum power: 100 (value shown on product header)
• Discharge height: 2 (value shown on product header)
• Water pump capacity: 250 l/min (both variants)
• Water tank capacity: 930 l (both variants)
• Lift height at max. load capacity: 1,760 mm (DBM2500) / 2,060 mm (DBM3500)
• Drum rotation speed: 0 ÷ 26 rpm (DBM2500) / 0 ÷ 18 rpm (DBM3500)
• Key functional points: external drum/ground controls for unloading without moving the machine; dedicated DBM cab and drum housing; axles and brakes sized for mixer duty; self-loading bucket option.
