Mounted sprayer Micromax

nursery plantsfor vegetable cultivationhydraulic

Micromax is a rotary disc atomiser for the controlled droplet application (CDA) of most water-based agrochemicals, including herbicides, insecticides and fungicides. Thanks to the low volume CDA technology, Micromax only produces the spray droplet sizes that are appropriate for the particular application, resulting in considerable savings when compared to hydraulic nozzles. Optimal droplet sizes also minimise any risk of environmental contamination. Low volume application allows lower chemical doses and cost-effective use of adjuvants. It also allows the use of light spray vehicles so as to minimise soil compaction. Due to the lower liquid requirement, larger areas can be sprayed per tank load, resulting in savings in terms of cost, time and effort. Components The complete units are equipped with a tank system consisting of a 240-litre main tank, a 20-litre auxiliary tank for cleaning the machine and a 20-litre hand-washing tank. The stopcock system allows you to clean the machine after each application without having to empty the main tank. There is also a lance for cleaning the inside of the main tank once it has been emptied. Improved hydraulic circuit The flow passes through the control panel by means of the equipment's new solenoid valve, which has a membrane to isolate the spring and the shaft from the product being used, avoiding any contamination problems. -Highly versatile and compatible with both oil and water-based solutions -Economical spray usage -High work rate -Three disc rotation speeds to suit different applications -Reduced risk of spray drift
