3-point hitch sprayer TURBO-400LT

tractor-mountedfor orchardsvineyard

Overview
The Holvan TURBO-400LT is a tractor-mounted crop sprayer designed for orchards and vineyards. It combines a 400 L polyester chemical tank, a hydraulic mixing system and an easily cleanable water filter to ensure homogeneous solution preparation and reliable field application.

Key features

• 400 L polyester chemical tank with high chemical resistance.
• Italian AR1604 pump (160 L, 4-piston) delivering wide spraying capacity.
• Hot-dip galvanized hood/tank type for corrosion resistance.
• VDR50 control unit for accurate pressure management.
• Suspend-type three-point hitch mounting for secure fit and maneuverability.
• 14 nozzles/injectors to ensure uniform distribution to distant points.
• Pump pressure up to 40 Bar and fan diameter 75 Ø.
• Suitable for tractors of 48 HP and above.

Specifications (table)
Feature - Value
Model - Holvan Turbo 400
Commercial name/model shown on page - TURBO-400LT
Tank capacity - 400 L
Tank material - Polyester
Pump - AR1604 (160 L, 4 piston)
Tank type - Hot-dip galvanized
Nozzle / Injector count - 14
Required tractor power - Minimum 48 HP
Pump pressure - 40 Bar
Fan diameter - 75 Ø
Warranty - 2 Year Official Warranty

Technical specifications

• Model: Holvan Turbo 400
• Commercial name / model shown on page: TURBO-400LT
• Tank capacity: 400 L
• Tank material: Polyester
• Tank type / hood: Hot-dip galvanized
• Pump: AR1604 (160 L, 4 piston)
• Pump pressure: 40 Bar
• Number of nozzles/injectors: 14
• Fan diameter: 75 Ø
• Control unit: VDR50
• Mounting: Suspend type, 3-point hitch
• Required tractor power: Minimum 48 HP
• Warranty: 2 years (official)
