Wheel rake MKE18

side deliverymulti-rotor

The standard version has rake wheels with a diameter of 55” (1.4m) and tines with a diameter of 0.28” (7mm). As an alternative, and with no changes to the machine structure needed, it is possible to mount optional rake wheels with a diameter of 60’’ (1.52m) and tines with a diameter of 0.3” (7.5 mm). Each wheel, regardless of the diameter, is equipped with 40 tines made of top-quality spring steel. The hay rakes of the Magnum Evolution line are designed in such a way that adjustments are simple to accomplish. A lever acting on a sprocket equipped with a locking mechanism enables the width of the swathe to be adjusted easily and rapidly from about 3’ (0.91 m) to 6’ (1.8 m). Alternatively, this function can be performed by an optional hydraulic device enabling the adjustment of the swathe directly from the tractor. Each rake wheel has its own spring and adjustment chain enabling the correct pressure on the ground to be obtained regardless of the crop and of the type of ground. In order to adapt to extreme field conditions, hay rakes must be solid and sturdy. This is why the drawbar and the rake wings have been made using a large lattice framework of structural tubing to make them tough and fully reliable over time, however hard they are made to work. Despite their size, these machines are easy to handle and transport and very user-friendly. Optional accessory kits A series of optional kits can be mounted on this type of hay rake. These include a central kicker wheel kit, a rear hydraulic opening kit, a rear tandem wheel kit, a kit to open on one side only, a wind shield kit, a light kit, etc.
