Horse hay rack 2130060

wall-mounted

Presentation
Feeding rack with head passage in rubber strip designed to reduce cervical issues for horses. 3-ply reinforced construction. Available for delivery as a kit or mounted on a box.

Details

• 3-ply reinforced rack for stables
• Width 300 mm x Height 1800 mm, head passage width 310 mm
• Top tensioning on a tube Ø70 mm x 3 mm
• Lower fixing by anchors on L-profile 70 mm x 50 mm
• Reinforcement by Ø42 mm tubes, 2 per panel
• Delivery options: kit or mounted on a box

Assembly

• On low wall
• With double-feed chassis
• On plywood

Technical specifications

• Construction: rubber strip, 3-ply reinforced
• Dimensions: 300 mm (width) x 1800 mm (height)
• Head passage: width 310 mm
• Tension tube (top): Ø70 mm x 3 mm
• Lower fixing: by anchors on L-profile 70 mm x 50 mm
• Reinforcements: Ø42 mm tubes (2 per panel)
• Delivery options: kit or mounted on a box
• Assembly options: on low wall, double-feed chassis, on plywood
• SKU: 2130060
• Categories: Stable equipment, Equestrian infrastructure, Self-service (rubber strip) + tubular self-service, Standard or self-service racks
