Analysis software WM-Subsurface™

planningprecision agriculturefor soil

Overview
WM-Subsurface works with PTx Trimble’s WM-Drain® solution to plan optimal placement of tile and drains for surface and subsurface drainage projects. The software integrates field and geospatial data to produce consistent water table designs and verify drainage networks prior to installation.

Key benefits

• Improved field water control: plans tile and levee placement to achieve more consistent water tables and reduce nutrient loss.
• Multi-layer field analysis: overlay yield, soil type and aerial imagery to visualise fields from multiple perspectives.

Specifications

• 3D and angled data viewing with vertical exaggeration for field shape and slope visualisation
• Watershed zone delineation to support main, submain and lateral pipe placement
• Configurable contours at any interval to represent topography and relative elevations
• Flow arrows and tributary lines to trace natural surface water flows
• Support for layering aerial imagery with agronomic data (yield, soil type)
• Autoslope feature to generate optimal depth designs for consistent water tables
• Pipe sizing calculations and drainage verification to confirm network performance before installation

System requirements

• Desktop installation on Microsoft® Windows® 7 or later
