Sugar cane harvesting machine C620

self-propelled

Product overview
A next-generation medium-sized wheeled sugarcane harvester designed for small to medium-sized operations in dry or wet field conditions. Suitable for row spacing ≥ 1.1 m. Powered by a 260 hp engine.

Key advantages

• High harvesting capacity: up to ≥ 25 t/h.
• Fast field mobility: maximum travel speed of 12 km/h.
• Superior field adaptability: crawler undercarriage design delivers low ground pressure for reliable operation in wet sugarcane fields.
• Easy operation: full electronic control system with simplified, labor-saving operation.
• Easy maintenance: all service points are readily accessible; engine compartment equipped with maintenance lighting.

Harvesting system
Crop divider type: Conical divider
Divider tip spacing: 1100 mm
Topper height range: Standard: 890–3000 mm; Optional: height extender (+500 mm)
Elevator discharge height: 4000 mm
Elevator swing angle: ±85°

Engine
Model: Cummins National III, 6.7 L, 6-cylinder engine
Rated power @ 2100 rpm: 194 kW, 260 hp

Other features

• Operator control system: full electro-hydraulic control system with multi-function joystick (harvesting) and separate left joystick (travel)
• Air conditioning: A/C (cooling only)
• Remote telematics: standard
• Video monitoring system: standard harvesting video monitoring + rearview camera

Technical specifications

• Overall dimensions: 10210 × 2320 × 5408 mm (L × W × H)
• Wheel base / Track gauge: 1550 mm
• Turning radius: 1.62 m
• Operating weight: 11.61 t
• Max. travel speed: 12 km/h
• Max. gradeability: 25%
• Fuel tank capacity: 270 L
• Hydraulic tank capacity: 180 L
• Row spacing (page text): ≥1.1 m
• Row spacing (parameters table): ≥1.2 m
• Max. harvesting capacity: ≥25 t/h
• Engine model: Cummins National III, 6.7 L, 6-cylinder
• Rated power: 194 kW / 260 hp @ 2100 rpm
• Crop divider type: Conical divider
• Divider tip spacing: 1100 mm
• Topper height range: 890–3000 mm (optional +500 mm)
• Elevator discharge height: 4000 mm
• Elevator swing angle: ±85°
