Mesh irrigation filter ORON GS

stainless steelself-cleaningautomatic

Description
ORON GS offers the highest filtration capacity within the ORON range, delivering an efficient and reliable solution for installations handling high flows and low-quality water, especially in agricultural irrigation systems.

Key features

• Automatic cleaning without interrupting the flow.
• Large filtration surface suited to poor-quality water.
• High-performance stainless steel mesh.
• Low maintenance requirements.
• Compatible with automatic control units.
• Robust construction for demanding applications.

Technical specifications

• Standard filtration: 120 µm.
• Maximum working pressure: 10 bar.
• Minimum pressure for cleaning: 2 bar.
• Maximum operating temperature: 60 °C.
• Net filtration area: 110 cm².
• Mesh material: high-performance stainless steel.

Applications

• Waters with high solids load: the large filtration area reduces cleaning frequency and improves performance under demanding conditions.
• High-flow agricultural installations: ideal to protect drip irrigation systems, fertigation units and professional filtration headers.

Available models
Model | Connection | Maximum flow
ORH-GS 6″ | DN150 | 180 m³/h
ORH-GS 8″ | DN200 | 320 m³/h
ORH-GS 10″ | DN250 | 580 m³/h
