Carrot harvester machine CM-100E

parsniptractor-mounted1-row

Overview
The CM-100E is a tractor-mounted, single-row toplifter with a left-side loading elevator, designed for mechanical harvesting of carrots, parsnips and other root crops. Suited to smaller farms and compact tractors, the unit mounts on the tractor lower links and an interaxle attachment frame. A share loosens soil below the root while rotating conical pick-up rollers lift the haulm so roots can be extracted by the clamping belt. A hydraulically driven root cleaner removes adhering soil and a hydraulic cutting unit severs the tops at the base. Harvested roots are transferred to a collection trailer positioned alongside the machine via the cart elevator (630 mm width).

Standard equipment

• Rotatable conical pick-up rollers
• Overload protection (shear bolts) for the conical pick-up rollers
• Share arm, cranked to the right, with offset mounted share blade
• Mechanical stone protection (shear pin) to protect the share
• Height adjustment of the share in relation to main frame via spindle
• Pick-up belt, length 335"
• Pick-up belts, grooved surface "PK5"
• Speed adjustment of top lifter belt manually via flow control valve
• Fix mechanical attachment of the top lifter belt to the main frame
• 1x Hydraulically driven rotating root cleaner
• Speed adjustment of root cleaners manual via flow control valve
• Height adjustment of root cleaner manually, with clamping screws at a fixed position
• Spring-loaded belt cleaners at the rear deflection
• Mechanical belt tensioner (turnbuckle)
• Cutting unit driven by one hydraulic motor
• Cart elevator with hydraulically adjustable centre section and mechanically adjustable elevator head
• Width of cart elevator 630 mm
• Elevator web, pitch 28 mm, rubber covered, incl. flight slats at distance 300 mm
• Speed adjustment of cart elevator manual via flow control valve
• Wheels 10,0/75 x 15,3
• Operator unit "i6": Control box for switching on / off hydraulic features

Technical specifications
Number of rows: 1
Input speed p.t.o.-shaft: 540 rpm
Length of pick-up belt: 335"
Wheels: 10.0/75-15.3
Cart elevator width: 630 mm
Elevator web pitch: 28 mm (rubber covered, incl. flight slats 300 mm)

Model / Technical details

• Model: CM-100E
• Type: Tractor mounted, single-row toplifter
• Intended crops: Carrots, parsnips and other root crops
• Rows: 1
• Drive / PTO speed: 540 rpm
• Pick-up belt length: 335"
• Top lifter belt: grooved surface "PK5", manual speed adjustment
• Cart elevator: width 630 mm, manual speed adjustment, hydraulically adjustable centre section
• Root cleaner: hydraulically driven rotating root cleaner, manual speed/height adjustment
• Cutting unit: hydraulic motor driven, synchronized knives
• Wheels: 10,0/75 x 15,3
• Operator unit: i6 control box
