Trough DTA series

Overview
Kongskilde's DTA trough augers provide an efficient, cost-effective solution for horizontal conveying of grain and other granular materials in agricultural and light industrial bulk-handling systems. Designed for feeding, transferring and distributing material between silos, dryers and processing stages, the DTA range combines a closed trough design with robust shaft support for reliable operation.

How DTA Trough Augers Work
DTA trough augers consist of a rotating screw shaft housed within a closed trough. Rotation of the shaft conveys material along the trough horizontally or on slight inclines. Multiple inlets and outlets can be integrated to route material as required. Intermediate bearings support the shaft to allow smooth operation, reduce wear and enable the unit to run with minimal material present.

Benefits

• High conveying capacity: up to 30 tons per hour over effective distances up to 20 meters.
• Flexible routing: designed for bi-directional conveying and configurable with multiple inlets and outlets.
• Material protection: closed trough reduces contamination and spillage.
• Low maintenance: screw shaft on intermediate bearings reduces wear and downtime.

Accessories

• Multiple inlets: allow introduction of material from several points on the same unit.
• Multiple outlets: enable distribution to different locations from a single auger.
• Manual outlet control: outlets operated manually, with option to control directly or remotely via pulley and cord.

Applications
Kongskilde DTA trough augers are suited to agricultural bulk handling and light industrial grain processing, including transfer between silos, feeding dryers and integrating material flow across processing lines.

Technical specifications

• Conveying capacity: up to 30 tons per hour.
• Effective conveying distance: up to 20 meters.
• Conveying orientation: horizontal or slight inclinations; bi-directional operation.
• Construction: closed trough to protect material and reduce spillage.
• Shaft and bearings: screw shaft mounted on intermediate bearings allowing operation with minimal wear and the ability to run without material.
• Inlets/outlets: configurable with multiple inlets and outlets on the same unit.
• Outlet control: manual control, operable directly or remotely via pulley and cord.
• Typical model sizes referenced: DTA 102, 127, 152, 205, 254.
