Tray filler with bale opener SB03

big volumes

Product
The SB03 is a high-speed production-line machine for uniform filling of trays, hanging baskets and nursery pots. It is suitable for light to heavy soils, bulk soil delivery and can be integrated under a bale breaker for continuous feeding.

Production

• Variable-speed soil hopper
• Variable-speed conveyor
• Standard hopper capacity: 2 cubic yards (≈1.53 m³)
• Compatible container size: up to 18 in (45 cm) wide and 15 in (38 cm) high
• Fill rate: up to 2,500 hanging baskets or trays per hour

Power

• 220 V single phase 60 Hz (standard)
• 1 × 3 hp AC drive (27.2 A) for soil delivery
• 1 × 1/2 hp DC motor (2.5 A) for conveyor
• 1 × 1/3 hp AC motor (1.85 A) for brush
• Other voltages/configurations available as options

Options

• SB03FOR option for forestry trays
• Additional hopper (+2 cubic yards)
• Vibrating system for uniform filling of plug trays
• Pneumatic wheels and tow bar
• Power transfer to drive SB10 conveyor at inlet and/or outlet
• Remote potentiometer
• Water injection system
• Fertilizer feeder
• Drill system
• Start/stop connection from transplanter

Technical specifications

• Model: SB03
• Application: tray and pot filling (flat filler, pot filler, plug-tray configurations)
• Soil hopper capacity: 2 cubic yards standard (optional extra 2 cubic yards)
• Container compatibility: up to 18 in (45 cm) wide and 15 in (38 cm) high
• Max fill rate: up to 2,500 trays/h
• Electrical: 220 V single phase 60 Hz standard; other voltages available
• Drive motors: 1 × 3 hp AC (27.2 A) soil; 1 × 1/2 hp DC (2.5 A) conveyor; 1 × 1/3 hp AC (1.85 A) brush
• Available accessories: vibrating system, pneumatic wheels & tow bar, power transfers, remote potentiometer, water injection, fertilizer feeder, drill system, transplanter start/stop connection
