Plug TEE

Short description
Conical closing plug in zinc-coated steel with external hex and conical thread.

Images

• TEE.jpg
• TEE_DIS.jpg

Technical info - BSPT

• 1GTEE1CV — Thread 1/4" — t: 6 mm — f: 13 mm — e: 10 mm — Weight: not specified
• 1GTEE2CV — Thread 3/8" — t: 7 mm — f: 13 mm — e: 13 mm — Weight: 23 g
• 1GTEE3CV — Thread 1/2" — t: 6 mm — f: 15 mm — e: 17 mm — Weight: 38 g

Technical info - MB METRIC

• 1MTEE2CV — Thread 16 x 1,5 — t: 6 mm — f: 10 mm — e: 10 mm — Weight: not specified
• 1MTEE3CV — Thread 18 x 1,5 — t: 6 mm — f: 12 mm — e: 13 mm — Weight: 26 g
• 1MTEE5CV — Thread 22 x 1,5 — t: 8 mm — f: 13 mm — e: 17 mm — Weight: 39 g

Characteristics / technical specifications

• Type: conical closing plug
• Material: zinc-coated steel
• Head: external hex
• Thread type: conical thread (BSPT and MB metric options)
• Available BSPT codes and threads: 1GTEE1CV (1/4"), 1GTEE2CV (3/8"), 1GTEE3CV (1/2")
• Available MB metric codes and threads: 1MTEE2CV (16 x 1,5), 1MTEE3CV (18 x 1,5), 1MTEE5CV (22 x 1,5)
• Dimensions t, f, e and weights listed per code in the technical tables above
