Wastewater pump controller DSEG8600

User Configurable as: Single-Set Controller / Multi-Set Controller/ Mains (Utility) Controller / Group Controller The G8600 is a parallel genset controller with integral heater designed for complex paralleling applications. The G8600 can be configured to provide paralleling for up to 4,032 generators on a single site and provides a wide range of high-end features for multiple application environments. The module is configurable for use as a single-set controller, multi-set controller, mains (utility) controller or group controller. Overall (W x H x D) 248 mm x 182.6 mm x 45.2 mm / 9.77” x 7.19” x 1.78” Panel Cut-Out (W x H) 220 mm x 160 mm / 8.66” x 6.3” Maximum Panel Thickness 8 mm / 0.31” Product Highlights Key Features Multiple bus sectioning Group controller functionality Spinning reserve Load demand schemes Advanced MSC link (AMSC) Advanced PLC functionality Multi-purpose PIDs Phase locking Virtual inputs On-screen mimic (SLDs) Multiple application support Multi-level pin protected front panel editor Integral LCD display heater Enhanced high-resolution 240 x 128 pixel display Single or multiple generator control Latest ECU / ECM support Load sharing & VAr sharing Virtual shared inputs / outputs and data via AMSC Touch screen panel PC support (DSE SCADA) Zero Sequence voltage protection Integral gasket (IP65 protection) Specification Cranking Dropouts Able to survive 0 V for 100 mS, providing supply was at least 10 V before dropout and supply recovers to 5 V. This is achieved without the need for internal batteries. LEDs and backlight will not be maintained during cranking. Maximum Operating Current 700 mA at 12 V, 350 mA at 24 V
