Flatbed trailer OL TDK 80 S K

2-axleagricultural8 ton

OL TDK 80 S K - Tandem axle combination tipper Permissible total weight: 8.0 t Internal dimensions of the platform: 4,000 x 2,110 (2,060) x 500 mm Imagine starting your work in the morning with everything you need: a tipper with a 3-sided tipping function for flexible unloading, a crane for loading goods, and a timber trailer. OEHLER combines the advantages of three machines in just one vehicle. This reduces your costs, saves time, and gives you maximum flexibility – whether in agriculture, forestry, construction, or transportation. Standard tires: 13.0/75-16/10PR Approx. curb weight: without crane: 1,800 kg Standard side wall: 500 mm Platform height approx.: 1,180 mm Base plate: 4 mm continuous, unwelded Maximum axle load capacity: 11,000 kg Tilt cylinder stages: 4 Cylinder stroke length: 1,500 mm Cylinder stages Ø mm: 60-75-90-105 Maximum operating pressure: 200 bar Required oil quantity: 8.3 l Brake: Automatic return (BPW) Electrics: 12-volt lighting system, rear socket Other: Wheel chocks - Torsion-resistant chassis made of sturdy closed C-frame, extended, platform reinforcement with 8 stanchions - Steel side walls, individually suspended with rubbing strip, grain slider - Central locking on 3 sides, bolted corner stanchions - BPW axle: suitable for 25/40 km/h - Foldable support wheel - ACC dip primer and powder coating - Tilting device: 4-stage lift cylinder, 1,050 mm lift, hard chrome-plated piston rod, gimbal mounting, automatic lift limitation - TÜV approval up to 25 km/h at maximum payload - Various crane superstructures (also as Z-crane) available - Robust, low design with high maneuverability - From 100% 3-sided tipper – with little conversion time – to full-fledged timber transport trailer - Optional equipment with hydraulic oil brake or dual-circuit compressed air system
