Mounted wood chipper TRB series

hydraulic supply

Short description
Branch and weed shredder TRB series designed for small and medium tractors. Available in fixed or laterally displaceable frames with reinforced versions for heavier vegetation. Working widths from 120 to 240 cm; recommended tractor power 35–120 HP.

Standard

• Chassis in anti-wear steel plate.
• Bearing holder in special steel.
• High-performance hammers guaranteed against breakage.
• Front wear-plate skirts.
• Roller bearing holder with protected grease nipples.
• Rear roller Ø 170 mm with roller cleaner.

Description
Designed to shred herbaceous vegetation and shrubs of 3–5 cm diameter. Reinforced TRB versions can crush stems up to 12–13 cm (TRB / TRB-REV); the related TBF-RAW and TRBF models reach up to 20 cm. Machines are available fixed or with mechanical/hydraulic lateral displacement. Manufactured in high-quality steel plate with multiple lines of counter-hammers; cutting elements include high-quality hammers and steel fasteners. Suitable for gardening, small farms, vineyards, orchards and general green-space maintenance.

Technical features (table)
Code | Model | Working width | Number of hammers | Tractor power | Weight kg
9990207 | TRB-120 | 120 cm | 10 | 35-45 HP | 606
9990217 | TRB-150 | 150 cm | 12 | 45-60 HP | 655
9990227 | TRB-165 | 165 cm | 12 | 50-65 HP | 710
9990233 | TRB-180 | 180 cm | 14 | 60-75 HP | 744
9990243 | TRB-200 | 200 cm | 18 | 70-85 HP | 832
9990249 | TRB-220 | 220 cm | 18 | 80-95 HP | 860
99902511 | TRB-240 | 240 cm | 20 | 90-120 HP | 950

Options

• Blades kit.
• Clutch or freewheel.

Technical specifications

• Applicable vegetation: herbaceous and shrubs 3–5 cm; reinforced versions crush up to 12–13 cm (TRB/TRB-REV) or up to 20 cm (TBF-RAW/TRBF).
• Machine lengths (reinforced TRB models): 1.20 m to 2.50 m.
• Construction: chassis in anti-wear steel plate; special-steel bearing holders.
• Cutting system: multiple lines of counter-hammers; high-quality hammers and steel fasteners.
• Drive/adjustment: mechanical or hydraulic lateral displacement available.
• Roller: Ø 170 mm with protected grease nipples and roller cleaner.
• Intended use: gardening, small farms, vineyards, orchards, green areas, and low brush management.
• Models and requirements: see technical table for codes, working widths, hammer counts, recommended tractor power and weights.
• Available options: blades kit; clutch or freewheel.
