Grain bag unloader RGU 1218 CD

for grainswith wheels

Overview
RENN grain bag unloaders are designed for on-farm unloading and plastic recovery. The RGU 1218 CD and FBU 1014 models handle 9', 10' and 12' diameter grain bags and require minimal power to operate. A continuous-flow unloading system pulls the unloader and power unit into the bag while high-capacity discharge augers move grain quickly into transport or storage.

Superior Plastic Management
Onboard recycle-ready plastic management uses a hydraulic ratchet rewind to wind spent bags onto rear rewind spools, producing a compact, recycle-ready package. The RENN roller and hold-down system guide the bag onto drive spools to reduce stress and spillage. The hydraulic rewind spool is standard or optional depending on model, enabling cleaner collection and easier handling for recycling.

RENN FARMBOY UNLOADER 1014
The FBU 1014 unloads 9' and 10' bags with a volumetrically balanced transfer box feeding a 14 in. lift auger and a 12 in. folding discharge auger to maximize throughput and maintain steady grain flow.

Unloader Features

• 540 PTO (FBU 1014) or 1000 PTO (RGU 1218 CD) with shear bolt protection
• Mechanically driven inclined discharge auger with CV joint
• Left- or right-hand discharge options (right-hand only on FBU 1014)
• Discharge auger sizes 14 in. to 18 in., model dependent
• Sweep auger options from 9 in. to 11 in.
• Bag hold-down frame, control rollers and lift roll
• Bag separation knives to prevent bridging
• Hydraulic ratcheting bag collection and rewind (optional hydraulic rewind on FBU 1014)

FARMBOY UNLOADER 1014 — Specifications
Lift Auger (in.) : 14
Folding Discharge Auger (in.) : 12
Sweep Auger (in.) : 9
Horizontal Discharge Auger (in.) : N/A
Discharge Reach (in.) : 173
Transport Height (in.) : 96
Transport Width (in.) : 115
Maximum Rated Capacity : 150 bu./min / 4 t/min.
Tire Size : 12 - 16.5 6 Bolt
Minimum HP : 50
Minimum Hydraulic Gal./Min. : 4

RGU 1218 CD — Specifications
Lift Auger (in.) : 18
Folding Discharge Auger (in.) : N/A
Sweep Auger (in.) : 11
Horizontal Discharge Auger (in.) : 12
Discharge Reach (in.) : 194
Transport Height (in.) : 144
Transport Width (in.) : 105
Maximum Rated Capacity : 250 bu./min / 6.8 t/min.
Tire Size : 12.5 x 16 6 Bolt Rim
Minimum HP : 100
Minimum Hydraulic Gal./Min. : 10

Technical characteristics

• Compatible bag diameters: 9', 10', 12'
• Continuous-flow unloading system draws unloader and power unit into bag
• Onboard recycle-ready plastic management with hydraulic ratchet rewind
• High-capacity discharge augers (14 in.–18 in., depending on model)
• Sweep auger options: 9 in. (FBU 1014) to 11 in. (RGU 1218 CD)
• Discharge reach up to 194 in. (RGU 1218 CD)
• Transport dimensions vary by model (Height: 96 in. FBU 1014 / 144 in. RGU 1218 CD)
• Maximum rated capacity: 150 bu./min (FBU 1014) and 250 bu./min (RGU 1218 CD)
• Minimum PTO / horsepower: 540 PTO / 50 HP (FBU 1014); 1000 PTO / 100 HP (RGU 1218 CD)
• Minimum hydraulic flow: 4 gal./min (FBU 1014); 10 gal./min (RGU 1218 CD)
• Optional hydraulic rewind spool on FBU 1014
• Designed for operation in harsh field and weather conditions
