Straight snow blade NANOTECH NT Series

with hydraulic adjustment

Classification / General and building materials Features snow plow truck with GVW between 35 to 60 q.li and agricultural tractors with power between 35 and 80 hp with 30q.li. weight. Equipment Snow with a supporting steel structure and counter-plate quick fit conforms to the Statement of DIN 76060 / B. Front shear in one piece consisting HDPE polyethylene sheet. Knife scraping into two independent sectors, available in wear-resistant steel or neoprene (rubber). mechanical adjustment of the angle of the ground attack (incidence) .Production shock agent, using steel springs, exclusively on each of the wiper blade segment. These, in phase of collision with a rigid element, flex backwards (against the direction of travel) and, after passing the obstacle, are rotated in the vertical working position by the two pairs of springs. bearing structure in stove-enamelled steel with special anti-rust treatment and final enamel RAL 2011 (orange). Aileron HDPE black. overpressure valve for shock side impact, R2 pipes with fittings and standardized quick couplings. Operation Hydraulic, with hydraulic cylinders for tilting left / right and up / down. Sources of energy Electro-hydraulic power to 12 or 24 V can be installed on request (optional), the implement Snow. Alternatively, special hydraulic plant realized on the thrust means (2 distributors need to double effect of one or equipped with floating position). Commands for handling Pushbutton electro-hydraulic, with recommended length cable, combined with the electro-hydraulic control unit. Alternatively, commands already present on the vehicle if fitted with a suitable hydraulic system (es. Agricultural tractor).
